The Shamrock Controls 330 Ampere (A) Maximum Inductive AC Contactor from the F-Range 4 Pole series is a high-performance solution designed for industrial applications. With a rated breaking capacity of 3000 A and a maximum power rating of up to 250 hp, this contactor ensures reliable and efficient operation. Meeting standards such as BSEN80947, IEC60947-1, IEC60947-4, and more, it is approved by CSA, IEC, and UL for quality assurance. Operating in ambient temperatures ranging from -60 to +80 ºC, this contactor is suitable for a wide range of environments, making it a versatile choice for government and institutional procurement needs.
Product Specifications
Control Circuit Characteristics Average Consumption At 20 Degree
10 V·A
Control Circuit Characteristics Power Circuit Connection Tighten
1.2 N·m
Control Circuit Characteristics Power Dissipation Per Pole For A
31 W
Dimensions Diameter
M10
Dimensions Dimension A
250 mm
Dimensions Dimension B
206 mm
Dimensions Dimension B1
145 mm
Dimensions Dimension B2
375 mm
Dimensions Dimension C
220 mm
Dimensions Dimension G
202.5 mm
Dimensions Dimension G1
96 mm
Dimensions Dimension I
147 mm
Dimensions Dimension J
106 mm
Dimensions Dimension J1
120 mm
Dimensions Dimension L
147 mm
Dimensions Dimension M
181 mm
Dimensions Dimension P
48 mm
Dimensions Dimension Q
43 mm
Dimensions Dimension Q1
74 mm
Dimensions Dimension S
25 mm
Dimensions Dimension S1
44.5 mm
Dimensions Dimension Y
38 mm
Dimensions Dimension Z
20.5 mm
Dimensions Minimum Electrical Tolerance According To Operating V
10 mm
Pole Characteristics Bar Size
30 x 5 mm
Pole Characteristics Bolt Diameter
10 mm²
Pole Characteristics Cable With Lug Size
240 mm
Pole Characteristics Maximum Power Rating At 200 Voltage
75 hp
Pole Characteristics Maximum Power Rating At 230 Voltage
100 hp
Pole Characteristics Maximum Power Rating At 480 Voltage
200 hp
Pole Characteristics Maximum Power Rating At 600 Voltage
250 hp
Pole Characteristics Rated Insulation Voltage
1500 V
Pole Characteristics Rated Operational Voltage
0 to 1000 V
Specifications Minimum Electrical Tolerance According To Breakin
15 mm
