Shamrock Controls 400A 4 Pole Inductive AC Contactor
Shamrock Controls 400A 4 Pole Inductive AC Contactor
SKU:CON-fe4426
Reliable 400A 4 Pole Inductive AC Contactor by Shamrock Controls - CSA, IEC, UL Approved. Versatile for industrial applications.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
Shamrock Controls 400A 4 Pole Inductive AC Contactor
$349.99
Quantity: 1
Claim Your Seller Account
Shamrock Controls 400A 4 Pole Inductive AC Contactor
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Shamrock Controls 400 Ampere Maximum Inductive AC F-Range 4 Pole Contactor is a reliable and efficient electrical component designed for industrial applications. With a rated insulation voltage of 1500V and a maximum inductive AC of 400A, this contactor meets BSEN80947, IEC60947-1, IEC60947-4, JEM1008, NFCEN60947, and VDE0660 standards. Approved by CSA, IEC, and UL, this contactor ensures high performance in a wide range of operating conditions, from -60 to +80°C ambient air storage temperature. It is suitable for various power ratings and control circuit voltages, making it a versatile choice for institutional buyers.
Product Specifications
Control Circuit Characteristics Average Consumption At 20 Degree
0.9 V·A
Control Circuit Characteristics Operational Control Voltage Limi
0.85 to 110 Uc
Control Circuit Characteristics Power Circuit Connection Tighten
1.2 N·m
Control Circuit Characteristics Power Dissipation Per Pole For A
45 W
Control Circuit Characteristics Rated Control Circuit Voltage At
48 to 600 V
Dimensions Dimension A
261 mm
Dimensions Dimension B
205 mm
Dimensions Dimension B1
209 mm
Dimensions Dimension B2
375 mm
Dimensions Dimension C
220 mm
Dimensions Dimension G
170 mm
Dimensions Dimension G1
170 mm
Dimensions Dimension I
119 mm
Dimensions Dimension J
67.5 mm
Dimensions Dimension L
145 mm
Dimensions Dimension M
181 mm
Dimensions Dimension P
48 mm
Dimensions Dimension Q
43 mm
Dimensions Dimension Q1
74 mm
Dimensions Dimension S
25 mm
Dimensions Dimension S1
44.5 mm
Dimensions Maximum Dimension G
150 mm
Dimensions Maximum Dimension G1
240 mm
Dimensions Minimum Dimension G
86 mm
Dimensions Minimum Dimension G1
156 mm
Dimensions Minimum Electrical Tolerance According To Operating V
15 mm
Pole Characteristics Bar Size
30 x 5 mm
Pole Characteristics Bolt Diameter
10 mm²
Pole Characteristics Cable With Lug Size
2 x 150 mm
Pole Characteristics Maximum Power Rating At 200 Voltage
100 hp
Pole Characteristics Maximum Power Rating At 230 Voltage
125 hp
Pole Characteristics Maximum Power Rating At 480 Voltage
250 hp
Pole Characteristics Maximum Power Rating At 600 Voltage
300 hp
Pole Characteristics Rated Insulation Voltage
1500 V
Pole Characteristics Rated Operational Voltage
0 to 1000 V
Specifications Minimum Electrical Tolerance According To Breakin
20 mm
