Shamrock Controls 40A DP Contactor, 2-Pole 480V Coil Voltage
Shamrock Controls 40A DP Contactor, 2-Pole 480V Coil Voltage
SKU:DPC-ae39d3
Reliable 40A 480V 2-Pole DP Contactor for motors, lighting, and more.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Shamrock Controls 40A DP Contactor, 2-Pole 480V Coil Voltage
$49.99
Quantity: 1
Claim Your Seller Account
Shamrock Controls 40A DP Contactor, 2-Pole 480V Coil Voltage
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Shamrock Controls 40 Ampere Definite Purpose Contactor is specifically designed for the control of motors, power supplies, lighting, HVAC fans, and compressors. This 2-pole contactor features a resistive rating current of 40A, ensuring reliable and efficient operation. With a coil voltage of 480V and a durable construction, this contactor is built to withstand demanding industrial environments. It offers a long expected life of 200,000 operations, making it a dependable choice for various applications.
Product Specifications
Coil Data Coil Voltage
480 V
Coil Data Duty Cycle
Continuous
Coil Data Frequency
50 Hz
Coil Data Minimum Initial Insulation Resistance
100 MΩ
Coil Data Normal Inrush Apparent Power
65 V·A
Coil Data Sealed Apparent Power
7.5 V·A
Environment Ambient Air Dampness Around The Device Relative Humi
45 to 85 %
Environment Ambient Air Temperature
40 to 65 ºC
Environment Coil Apply Voltage At 50 Hertz Hz Frequency
75 to 110 %
Environment Maximum Operating Altitude Above Sea Level
2000 m
Environment Operating Temperature
-5 to 55 ºC
Specifications Locked Rotor Per Pole Current At 240 Alternating
150 A
Specifications Number Of Poles
2
Technical Data Full Load Expected Life
200000 Operations
Technical Data Full Load Inductive Current
30 A
Technical Data Locked Rotor Per Pole Current At 480 Alternating
125 A
Technical Data Locked Rotor Per Pole Current At 600 Alternating
100 A
Technical Data Mechanical Alternating Current Ac Coil Operations
2 Million
Technical Data Minimum Contact Data At 120 Alternating Current V
3 A
Technical Data Resistive Rating Current
40 A
