Shamrock Controls Mini Control Relay - 4 NC Composition DC
Shamrock Controls Mini Control Relay - 4 NC Composition DC
SKU:REL-d4d2c0
Reliable 4 NC DC Mini Control Relay - Ideal for Precision & Durability
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Shamrock Controls Mini Control Relay - 4 NC Composition DC
$39.99
Quantity: 1
Claim Your Seller Account
Shamrock Controls Mini Control Relay - 4 NC Composition DC
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Shamrock Controls Mini Control Relay features 4 Normally Closed (NC) contacts suitable for Direct Current (DC) applications. With a high mechanical and electrical life, this relay is designed for durability and long-term reliability. Ideal for industrial and institutional settings requiring precise control and efficient performance.
Product Specifications
Accessories Auxiliary Contact Blocks Ith 10a
Item #: TA1-M20Composition: 2 Normally Open (NO)Mounting: Front MountItem #: TA1-M02Composition: 2 Normally Closed (NC)Mounting: Front MountItem #: TA1-M11Composition: 1 Normally Open (NO) + 1 Normally Closed (NC)Mounting: Front MountItem #: TA1-M40Composition: 4 Normally Open (NO)Mounting: Front MountItem #: TA1-M31Composition: 3 Normally Open (NO) + 1 Normally Closed (NC)Mounting: Front MountItem #: TA1-M22Composition: 2 Normally Open (NO) + 2 Normally Closed (NC)Mounting: Front MountItem #: TA1-M13Composition: 1 Normally Open (NO) + 3 Normally Closed (NC)Mounting: Front MountItem #: TA1-M04Composition: 4 Normally Closed (NC)Mounting: Front MountItem #: TA8-M10Composition: 1 Normally Open (NO)Mounting: Side MountItem #: TA8-M01Composition: 1 Normally Closed (NC)Mounting: Side Mount
Accessories Coil Suppressor Varistor
Item #: TA9-M980/1Voltage: 24 to 48 Alternating Current (AC) Voltage (V)Item #: TA9-M980/2Voltage: 60 to 127 Alternating Current (AC) Voltage (V)Item #: TA9-M980/3Voltage: 200 to 240 Alternating Current (AC) Voltage (V)Item #: TA9-M980/4Voltage: 12 to 24 Direct Current (DC) Voltage (V)Item #: TA9-M980/5Voltage: 30 to 72 Direct Current (DC) Voltage (V)Item #: TA9-M980/6Voltage: 100 to 127 Direct Current (DC) Voltage (V)Item #: TA9-M980/7Voltage: 200 to 250 Direct Current (DC) Voltage (V)
Accessories Front Mounted Electronic Timers
Item #: TA2-M/1NVoltage: 24 to 48 Alternating Current (AC)/Direct Current (DC) Voltage (V)Time: 0.1 to 30 Seconds (s)Delay: OnItem #: TA3-M/1FVoltage: 24 to 48 Alternating Current (AC)/Direct Current (DC) Voltage (V)Time: 0.1 to 30 Seconds (s)Delay: OffItem #: TA2-M/2NVoltage: 100 to 240 Alternating Current (AC) Voltage (V)Time: 0.1 to 30 Seconds (s)Delay: OnItem #: TA3-M/2FVoltage: 100 to 240 Alternating Current (AC) Voltage (V)Time: 0.1 to 30 Seconds (s)Delay: Off
Accessories Note For Accessories
Mechanical Interlock ComponentsCable Kits for Line and Load Sides
Inductive Load Inductive Load Makingbreaking Direct Current Dc D
0.7 A
Inductive Load Inductive Load Rated Direct Current Dc Duty At 12
1.1 A
Inductive Load Inductive Load Rated Direct Current Dc Duty At 24
0.55 A
Inductive Load Inductive Load Rated Direct Current Dc Duty At 48
0.31 A
Inductive Load Inductive Load Rated Direct Current Dc Duty At 60
0.2 A
Resistive Load Resistive Load Rated Direct Current Dc Duty At 12
5 A
Resistive Load Resistive Load Rated Direct Current Dc Duty At 24
3 A
Resistive Load Resistive Load Rated Direct Current Dc Duty At 48
2.5 A
Resistive Load Resistive Load Rated Direct Current Dc Duty At 60
1 A
Specifications Composition
4 Normally Closed (NC)
Specifications Controller Type
Direct Current (DC)
Specifications Direct Current Dc Reference Code For 2460 Volt V
BD
Specifications Electrical Life At Alternating Current Ac12 Duty
0.25 Million Operation Cycles
Specifications Electrical Life At Alternating Current Ac15 Duty
0.50 Million Operation Cycles
Specifications Electrical Life At Direct Current Dc13 Duty Cycle
0.50 Million Operation Cycles
Specifications Mechanical Life
20 Million Operation Cycles
Specifications Operation Per Hour
1800
