Shamrock Controls Mini Overload Relay - 4 to 6 Ampere (A)
Shamrock Controls Mini Overload Relay - 4 to 6 Ampere (A)
SKU:REL-4ae50c
Shamrock Controls Mini Overload Relay with 4-6A current range, compact design, DIN rail or screw mountable. Ideal for industrial applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Shamrock Controls Mini Overload Relay - 4 to 6 Ampere (A)
$49.99
Quantity: 1
Claim Your Seller Account
Shamrock Controls Mini Overload Relay - 4 to 6 Ampere (A)
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Shamrock Controls Mini Overload Relay features a compact design for direct mounting on TC1-M6, TC1-M9, TC1-M12 contactor types. With a small width of 45mm, it offers a setting current range of 4 to 6 A, suitable for various industrial applications. This relay is DIN rail or screw mountable and comes with NO + 1 NC potential-free contacts. It complies with Trip Class 10A according to IEC60947-4-1/1S-13947-4-1 standards, ensuring reliable and efficient overload protection. Perfect for government and institutional use.
Product Specifications
Additional Information Additional Information
DIN rail or screw mountable with the optional base TA1-M09641 NO + 1 NC Potential free contactsTrip class 10A according to IEC60947-4-1/1S-13947-4-1Ambient/Manual reset site selectableTrip Free design
Alternating Current Ac15 11 Duty Alternating Current Ac15 11 Dut
0.3 A
Direct Current Dc13 11 Duty Direct Current Dc13 11 Duty Auxiliar
0.14 A
Note Note
Values are the ratings of NO contact under auto reset mode
Specifications Setting Current Range
4 to 6 A
Specifications Small Width
45 mm
