Shielded Waterproof Breakaway Connectors, 7-10 Pin
Shielded Waterproof Breakaway Connectors, 7-10 Pin
SKU:7AN-c28057
Reliable waterproof breakaway connectors for rugged environments. Ideal for C4I Systems, Military Vehicles & more.
Regular price
$69.99
Regular price
Sale price
$69.99
Unit price
per
Initiate Order
Shielded Waterproof Breakaway Connectors, 7-10 Pin
$69.99
Quantity: 1
Claim Your Seller Account
Shielded Waterproof Breakaway Connectors, 7-10 Pin
$69.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Jack Shielded Waterproof Breakaway Connectors are ideal for ruggedized commercial/military applications. Featuring insulation-piercing contact types, gold-plated brass materials, and axial push-pull motion, these connectors ensure reliable performance in severe environments. With a self-cleaning feature and watertight design up to 6 feet, they excel in C4I Systems, Military Vehicles, Telecommunications, and more.
Product Specifications
Applications 0
C4I SystemsMilitary VehiclesCommercial AircraftTelecommunications EquipmentMissiles and OrdnanceMedical EquipmentCommercial / Industrial Equipment
Features 0
Plug and Jack breakaway connectors designed to function in severe environmentsWatertight in up to 6 feet of waterMolded-in wiping-action contacts provide self-cleaning feature and eliminate issues with pin/socket open contactsDesigned for multiple cable diametersMiniature versions are 50% smaller than standard connectors while maintaining many of the same performance characteristics
Options 0
7- or 10-pin (miniature version only) contacts Solder-type contacts or insulation-piercing contacts Wire strain relief or over-molded versions available for all plugs and jacksPanel mount versions are available for both front- and rear-mount panelsShielding is available in all connector choicesAll standard connector options also available in miniaturized versions
Specifications Application
Ruggedized Commercial / Military
Specifications Conductors
7
Specifications Contact Current Capacity
3 A
Specifications Contact Material
Gold-plated Brass
Specifications Contact Resistance
⤠150 mV
Specifications Contact Types
Insulation Piercing
Specifications Disengagement Force
8 to 12 lb
Specifications Engagement Force
⤠14 lb
Specifications Insert Material
Thermoset Plastic
Specifications Mating
Axial Push-Pull Motion
Specifications Mating Cycles
5000
Specifications Plating Material
Black Anodize (standard) | Black Chrome (shielded)
Specifications Rear Accessory
Overmold Cap
Specifications Shell Material
Aluminum
Specifications Temperature
-55 to 85 ºC
