The PC-250 Epoxy Compound is a versatile 100% solids epoxy system with a low coefficient of thermal expansion and exceptional shock resistance. With a convenient 1:1 mix ratio by volume, this resin offers excellent moisture resistance and can be dispensable by machine. It cures at room temperature and is ideal for various applications requiring flexibility and durability.
Product Specifications
Cure Schedule 0
Demold time at 75 °F - 4 hours | Room temperature cure at 75 °F with full properties after 24 hours
Mixing Instructions 0
Pre-mix Part A and Part B separately. Then measure 1:1 by volume (A to B). Mix thoroughly scraping the sides and bottom of the container. Evacuate and then pour into mold or cavity.
Properties Cured Coefficient Of Thermal Expansion
7 x 10-6
Properties Cured Dielectric Constant According To American Socie
4.5
Properties Cured Shore A Hardness According To American Society
70 duro
Properties Cured Temperature Class
B
Properties Cured Thermal Conductivity
3.5 BTU-in/(ft2)(hr)(°F)
Properties Cured Water Absorption
0.1 %
Properties Uncured Color
Black or White (Part B) | Clear (Part A)
Properties Uncured Shelf Life At 70 F
12 m
Properties Uncured Viscosity At 25 C Cps American Society For Te
600 (Part A) | 2500 (Part B)
Specifications Dielectric Strength According To American Society
370 V/mil
Specifications Dissipation Factor According To American Society
0.08
Specifications Mixed Viscosity According To American Society For
900 to 1500 cps
Specifications Mix Ratio By Volume
1:1
Specifications Pot Life At 25 C 100 Gram G
15 to 20 min
Specifications Specific Gravity
1.12 | 1.12 (Part A) | 1.29 | 1.29 (Part B)
Specifications Tensile Elongation According To American Society
25 %
Specifications Tensile Strength According To American Society Fo
3,500 psi
Specifications Type
Specialty Epoxies
Specifications Viscosity According To American Society For Testi
600 cps | 2500 cps
Specifications Volume Resistivity Viscosity At 25 C According To
7 x 1012 ohm-cm
