SID Series 15kVDC Straight Plug Cable Assembly
SID Series 15kVDC Straight Plug Cable Assembly
SKU:HIG-af80b9
Reliable 15kVDC high voltage connector with excellent corona characteristics for military and aerospace use.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
SID Series 15kVDC Straight Plug Cable Assembly
$129.99
Quantity: 1
Claim Your Seller Account
SID Series 15kVDC Straight Plug Cable Assembly
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The SID Series 15kVDC Straight Plug Cable Assembly is a high voltage connector designed for military and aerospace applications. This single-ended assembly features push-on/pull-off Silicone In-line Disconnect connectors with excellent corona characteristics and a unique interface sealing system ensuring reliability under extreme conditions. With a current rating of 5 Amp and operating temperature range of -55 to 95°C, this non-standard part is compatible with all SID receptacles, making it ideal for high-altitude applications up to 70,000 ft.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Body Properties Coupling Nut Material
Silicone
Contact Properties Contact Finish
Au with CRES Hood
Contact Properties Contact Material
BeCu
Contact Properties Contact Type
Female
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Single-Ended Straight Plug Cable Assembly
Specifications Coupling Style
Push-Pull
Specifications Current Rating
5 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Silicone
Specifications Mating Compatibility
Mates all SID receptacles
Specifications Operating Temperature
-55 to 95 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
N/A
Specifications Series
SID
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
20 kVDC at 70,000 ft. altitude (simulated)
Specifications Voltage Rating
15 kVDC
Specifications Wire Type
Non-Shielded
Wire Properties Accomodates Wire Diameter
0.180 in | 4.5 mm
Wire Properties Wire Insulation
Silicone | Silicone Rubber
