SID Series Double-Ended Hybrid Plug Cable Assembly
SID Series Double-Ended Hybrid Plug Cable Assembly
SKU:HIG-15384d
15 kVDC Hybrid Double-Ended Plug Cable Assembly for military and aerospace applications with superior corona discharge prevention and 70,000 ft. altitude performance.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
SID Series Double-Ended Hybrid Plug Cable Assembly
$249.99
Quantity: 1
Claim Your Seller Account
SID Series Double-Ended Hybrid Plug Cable Assembly
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The SID Series Double-Ended Hybrid Plug Cable Assembly is designed for high voltage applications up to 15 kVDC, offering a reliable connection for military and aerospace uses. With a unique sealing system ensuring performance under extreme conditions, including vibration, shock, and altitude of up to 70,000 ft., this assembly excels in corona discharge prevention. Featuring silicone insulation, gold-plated contacts, and compatibility with all SID receptacles, this non-standard part meets stringent standards for high voltage connectors.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Body Properties Coupling Nut Material
Silicone
Contact Properties Contact Finish
Au with CRES Hood
Contact Properties Contact Material
BeCu
Contact Properties Contact Type
Female
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Double-Ended Hybrid Plug Cable Assembly
Specifications Coupling Style
Push-Pull
Specifications Current Rating
5 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Silicone
Specifications Mating Compatibility
Mates all SID receptacles
Specifications Operating Temperature
-55 to 95 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
N/A
Specifications Series
SID
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
20 kVDC at 70,000 ft. altitude (simulated)
Specifications Voltage Rating
15 kVDC
Specifications Wire Type
Non-Shielded
Wire Properties Accomodates Wire Diameter
0.165 in | 4.1 mm
Wire Properties Wire Insulation
Silicone | Silicone Rubber
