Silicon Carbide Chopped Fiber - 0.00065mm Nominal Diameter
Silicon Carbide Chopped Fiber - 0.00065mm Nominal Diameter
SKU:SIL-d95e9f
Discover strength and durability with Goodfellow Corp. Silicon Carbide Chopped Fiber - 0.00065mm Nominal Diameter. Ideal for high-temp applications.
Regular price
$75.99
Regular price
Sale price
$75.99
Unit price
per
Initiate Order
Silicon Carbide Chopped Fiber - 0.00065mm Nominal Diameter
$75.99
Quantity: 1
Claim Your Seller Account
Silicon Carbide Chopped Fiber - 0.00065mm Nominal Diameter
$75.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your material's strength and resilience with our Goodfellow Corp. Silicon Carbide Chopped Fiber. Featuring a nominal diameter of 0.00065mm and a Length of 0.01mm, these fibers in Beta Whiskers form offer exceptional hardness, Vickers rating at 2500 Kgf mm-2. With a density of 3.200 g·cm-3 and a melting point range of 2650.00 to 2950.00 ºC, this fiber is ideal for high-temperature applications. Its excellent resistance to abrasives and chemicals makes it a durable choice for composite materials.
Product Specifications
Material Material
Silicon CarbideSilicon Carbide was first prepared in the early 1800's. It was in commercial production by 1892, as a powder for grinding and cutting, having a Mohs hardness of 9-10 (almost as hard as Diamond). Nicalon continuous multi-filament tow consists of fine filaments of ultra-fine Ã-SiC crystals, giving strong particle bonding. This fiber has high strength and a high modulus in a high temperature atmosphere. It is oxidation resistant, with a high wettability and is consequently used in composites with metals, plastics and ceramics. A thicker monofilament, also used for composites, is also available from Goodfellow in 3 versions which differ only in their outer coating (used to improve adhesion to, and resist degradation by, the matrix of a composite). This monofilament is made by a chemical vapor deposition (CVD) process around a fine tungsten wire.
Mechanical Properties Hardness Vickers
2500 Kgf mm-2
Physical Properties Density
3.200 g·cm-3
Specifications Form
Chopped Fiber
Specifications Length
0.01 mm
Specifications Nominal Diameter
0.00065 mm
Specifications Product Shape
Beta Whiskers
Specifications Weight
50 to 100 g
Thermal Properties Melting Point
2650.00 to 2950.00 ºC
Tolerances Fiber Length Tolerance
-1 % | +5 %
Tolerances Nominal Diameter Tolerance
25 %
Tolerances Tex Number Tolerance
10 %
Tolerances Tolerance For Number Of Strands
10 %
Type Type
Single CrystalCeramicCeramics are non-metallic, non-organic materials. They exhibit excellent resistance to high temperatures. Although they have comparatively low densities, they are extremely hard but tend to be brittle. They show good resistance to both abrasives and chemicals.
