Silicon Carbide Fiber | 0.015mm Diameter | SiC Filament
Silicon Carbide Fiber | 0.015mm Diameter | SiC Filament
SKU:SIL-eebfac
High-performance 0.015mm Silicon Carbide Fiber for superior strength and durability in extreme conditions.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Silicon Carbide Fiber | 0.015mm Diameter | SiC Filament
$59.99
Quantity: 1
Claim Your Seller Account
Silicon Carbide Fiber | 0.015mm Diameter | SiC Filament
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 0.015 Micrometer Silicon Carbide Fiber is a premium-quality product designed for high-performance applications. With a filament diameter of 0.015mm and excellent mechanical properties, this fiber offers exceptional tensile strength and durability. It has a Vickers hardness of 2500 Kgf mm-2, making it highly resistant to wear and abrasion. Its superior thermal properties, including a high melting point of 2650-2950°C, ensure stability in extreme conditions. Manufactured by Goodfellow Corp., this fiber is ideal for use in composites, metals, plastics, and ceramics.
Product Specifications
Electrical Properties Form Dielectric Constant Form
7.0 to 9.0
Material Material
Silicon CarbideSilicon Carbide was first prepared in the early 1800's. It was in commercial production by 1892, as a powder for grinding and cutting, having a Mohs hardness of 9-10 (almost as hard as Diamond). Nicalon continuous multi-filament tow consists of fine filaments of ultra-fine Ã-SiC crystals, giving strong particle bonding. This fiber has high strength and a high modulus in a high temperature atmosphere. It is oxidation resistant, with a high wettability and is consequently used in composites with metals, plastics and ceramics. A thicker monofilament, also used for composites, is also available from Goodfellow in 3 versions which differ only in their outer coating (used to improve adhesion to, and resist degradation by, the matrix of a composite). This monofilament is made by a chemical vapor deposition (CVD) process around a fine tungsten wire.
Mechanical Properties Form Extension To Break Form
1 %
Mechanical Properties Form Modulus Form
200 GPa
Mechanical Properties Form Tenacity Form
3 GPa
Mechanical Properties Hardness Vickers
2500 Kgf mm-2
Physical Properties Density
3.200 g·cm-3
Physical Properties Form Density Form
2.550 g·cm-3
Physical Properties Form Form Material
Nicalon SiC CF Tow
Specifications Filament Diameter
0.015 mm
Specifications Form
Fiber
Specifications Length
1 to 100 m
Specifications Number Of Filaments
500
Specifications Tex Number
209
Thermal Properties Form Coefficient Of Thermal Expansion Longitu
3 x10-6 K-1
Thermal Properties Form Specific Heat At 25 Degree Celsius C Tem
1 J K-1 kg-1
Thermal Properties Form Thermal Conductivity Form
12.0 W m-1K-1
Thermal Properties Melting Point
2650.00 to 2950.00 ºC
Tolerances Fiber Length Tolerance
-1 % | +5 %
Tolerances Filament Diameter Tolerance
25 %
Tolerances Tex Number Tolerance
10 %
Tolerances Tolerance For Number Of Filaments
10 %
Tolerances Tolerance For Number Of Yarns
10 %
Type Type
CeramicCeramics are non-metallic, non-organic materials. They exhibit excellent resistance to high temperatures. Although they have comparatively low densities, they are extremely hard but tend to be brittle. They show good resistance to both abrasives and chemicals.
