Silicon Carbide Monofilament Wire
Silicon Carbide Monofilament Wire
SKU:SIL-25bd25
Silicon Carbide Monofilament Wire - Versatile, high-performance wire with 0.1mm diameter & 1-20m length. TAA compliant & industry-standard.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Silicon Carbide Monofilament Wire
$99.99
Quantity: 1
Claim Your Seller Account
Silicon Carbide Monofilament Wire
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Silicon Carbide Monofilament Wire features a 0.1mm diameter and a length range from 1 to 20 meters. Coated with 0.001mm of pyrolytic carbon for enhanced adhesion, this monofilament is a non-metallic material suitable for various applications. With a Vickers hardness of 2500 Kgf mm-2, a density of 3.200 g·cm-3, and a melting point range of 2650.00 to 2950.00 ºC, this ceramic material offers exceptional mechanical and thermal properties. Rated TAA compliant and meeting stringent industry standards, this monofilament wire is a reliable choice for institutional and government procurement.
Product Specifications
Material Material
Silicon CarbideSilicon Carbide was first prepared in the early 1800's. It was in commercial production by 1892, as a powder for grinding and cutting, having a Mohs hardness of 9-10 (almost as hard as Diamond). Nicalon continuous multi-filament tow consists of fine filaments of ultra-fine Ã-SiC crystals, giving strong particle bonding. This fiber has high strength and a high modulus in a high temperature atmosphere. It is oxidation resistant, with a high wettability and is consequently used in composites with metals, plastics and ceramics. A thicker monofilament, also used for composites, is also available from Goodfellow in 3 versions which differ only in their outer coating (used to improve adhesion to, and resist degradation by, the matrix of a composite). This monofilament is made by a chemical vapor deposition (CVD) process around a fine tungsten wire.
Mechanical Properties Form Tensile Modulus Form
400.00 GPa
Mechanical Properties Form Tensile Strength Form
3.50 to 3.75 MPa
Mechanical Properties Hardness Vickers
2500 Kgf mm-2
Physical Properties Density
3.200 g·cm-3
Physical Properties Form Density Form
3.400 g·cm-3
Specifications Diameter
0.1 mm
Specifications Form
Monofilament
Specifications Length
1 to 20 m
Specifications Tungsten Diameter
0.01 mm
Thermal Properties Melting Point
2650.00 to 2950.00 ºC
Tolerances Diameter Tolerance
20 %
Tolerances Tolerance For Length Round
-1 % | +5 %
Type Type
CeramicCeramics are non-metallic, non-organic materials. They exhibit excellent resistance to high temperatures. Although they have comparatively low densities, they are extremely hard but tend to be brittle. They show good resistance to both abrasives and chemicals.
