Silicon Carbide (SiC) Sheet - 4mm Thickness
Silicon Carbide (SiC) Sheet - 4mm Thickness
SKU:SIL-13d302
High-quality 4mm Silicon Carbide (SiC) Sheet for industrial applications. Vickers hardness: 2500 Kgf mm-2. Durable & heat-resistant.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Silicon Carbide (SiC) Sheet - 4mm Thickness
$39.99
Quantity: 1
Claim Your Seller Account
Silicon Carbide (SiC) Sheet - 4mm Thickness
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Silicon Carbide (SiC) Sheet boasts a 4mm thickness and a compact 50x50mm size, making it a sturdy choice for various applications. Direct Sintered for enhanced durability, this sheet offers a Vickers hardness of 2500 Kgf mm-2. With a density of 3.200 g·cm-3 and a melting point ranging from 2650.00 to 2950.00 ºC, it combines strength with high-temperature resistance. Ideal for composite use in demanding environments, this sheet complies with stringent procurement standards.
Product Specifications
Material Material
Silicon CarbideSilicon Carbide was first prepared in the early 1800's. It was in commercial production by 1892, as a powder for grinding and cutting, having a Mohs hardness of 9-10 (almost as hard as Diamond). Nicalon continuous multi-filament tow consists of fine filaments of ultra-fine Ã-SiC crystals, giving strong particle bonding. This fiber has high strength and a high modulus in a high temperature atmosphere. It is oxidation resistant, with a high wettability and is consequently used in composites with metals, plastics and ceramics. A thicker monofilament, also used for composites, is also available from Goodfellow in 3 versions which differ only in their outer coating (used to improve adhesion to, and resist degradation by, the matrix of a composite). This monofilament is made by a chemical vapor deposition (CVD) process around a fine tungsten wire.
Mechanical Properties Hardness Vickers
2500 Kgf mm-2
Physical Properties Density
3.200 g·cm-3
Specifications Form
Sheet
Specifications Production Method
Direct Sintered
Specifications Size
50 x 50 mm
Specifications Thickness
4 mm
Specifications Thickness Tolerance
10 %
Thermal Properties Melting Point
2650.00 to 2950.00 ºC
Tolerances Tolerance For 100 Millimeter Mm Coil Length
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Disc Diameter
1 mm
Tolerances Tolerance For 100 Millimeter Mm Length 1 Light Tight
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 2 Light Tight
+2 % | -1 %
Type Type
CeramicCeramics are non-metallic, non-organic materials. They exhibit excellent resistance to high temperatures. Although they have comparatively low densities, they are extremely hard but tend to be brittle. They show good resistance to both abrasives and chemicals.
