Silicon Carbide Tube, 17mm OD
Silicon Carbide Tube, 17mm OD
SKU:SIL-e886e2
Premium Silicon Carbide Tube for durable industrial applications. Special price offer available.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Silicon Carbide Tube, 17mm OD
$129.99
Quantity: 1
Claim Your Seller Account
Silicon Carbide Tube, 17mm OD
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 17mm Outside Diameter Silicon Carbide Tube, part of the Silicon Carbide Alloys line by Goodfellow Corp., offers a length of 450mm with a wall thickness of 2mm. Made from Silicon Carbide, known for its exceptional hardness and resistance to high temperatures, this tube is ideal for applications requiring superior durability, abrasion resistance, and chemical inertness. Its unique composition makes it suitable for use in composite materials with metals, plastics, and ceramics, ensuring reliable performance in harsh environments. Despite minor damage, this high-quality tube remains available at a special price, making it a cost-effective solution for various industrial needs.
Product Specifications
Material Material
Silicon CarbideSilicon Carbide was first prepared in the early 1800's. It was in commercial production by 1892, as a powder for grinding and cutting, having a Mohs hardness of 9-10 (almost as hard as Diamond). Nicalon continuous multi-filament tow consists of fine filaments of ultra-fine Ã-SiC crystals, giving strong particle bonding. This fiber has high strength and a high modulus in a high temperature atmosphere. It is oxidation resistant, with a high wettability and is consequently used in composites with metals, plastics and ceramics. A thicker monofilament, also used for composites, is also available from Goodfellow in 3 versions which differ only in their outer coating (used to improve adhesion to, and resist degradation by, the matrix of a composite). This monofilament is made by a chemical vapor deposition (CVD) process around a fine tungsten wire.
Note Note
Please note this material is being offered at a special price due to slight damage.One piece only remaining.
Specifications Form
Tube
Specifications Inside Diameter
13 mm
Specifications Length
450 mm
Specifications Outside Diameter
17 mm
Specifications Wall Thickness
2 mm
Tolerances Tolerance For 100 Millimeter Mm Length Round
-1 % | +5 %
Tolerances Tolerance For 2 Millimeter Mm Outside Diameter
0.05 mm
Tolerances Tolerance For 5 Millimeter Mm Outside Diameter
5 %
Tolerances Wall Thickness Tolerance
10 %
Type Type
CeramicCeramics are non-metallic, non-organic materials. They exhibit excellent resistance to high temperatures. Although they have comparatively low densities, they are extremely hard but tend to be brittle. They show good resistance to both abrasives and chemicals.
