The Silicone Coated FEP Cable with Nomex Woven Protective Jacket is a high-performance solution for applications requiring superior dielectric properties and abrasion resistance. With a silicone-coated FEP insulation and a Nomex woven jacket, this cable offers exceptional durability and a reliable dielectric bond. Operating within a wide temperature range (-55 to +125 °C), this cable is designed with a 26 AWG tin-plated copper conductor for efficient power transmission. Ideal for high voltage applications up to 18 kVDC, this cable ensures reliable performance and longevity.
Product Specifications
Alternate Cable Part Number Equivalents Etched Part Number
178-8194
Alternate Cable Part Number Equivalents Silicone Coated Part Num
178-7598
Cable Wire Properties Etched
No
Cable Wire Properties Jacketed
Yes
Cable Wire Properties Silicone Coated
Yes
Cable Wire Properties Twisted Pair
No
Cable Wire Properties Twisted Shielded Pair
No
Specifications Conductor Diameter
0.060 in | 1.524 mm
Specifications Conductor Gauge
26 AWG
Specifications Conductor Material
Copper
Specifications Conductor Plating
Tin Plated
Specifications Conductor Strands
19/38
Specifications Default Color
Natural
Specifications Diameter Over Silicone Coating
0.060 in | 1.524 mm
Specifications Insulator Material
FEP
Specifications Operating Temperature
-55 to 125 ºC
Specifications Overall Diameter
0.060 in
Specifications Standardnon Standard
Standard Part
Specifications Voltage Rating
18 kVDC
