Silicone Coated High Voltage Microflex - 3kVDC Wire & Cable

Name: Silicone Coated High Voltage Microflex - 3kVDC Wire & Cable
Brand: Teledyne Reynolds
SKU: HIG-a61cf6
Price: 39.99 USD
Availability: OutOfStock

SKU:HIG-a61cf6

Discover the Silicone Coated High Voltage Microflex - 3kVDC Wire & Cable for superior dielectric bond & durability. Operates at -55 to 125°C.

$39.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Silicone Coated High Voltage Microflex is a reliable wire and cable solution with a silicone rubber coating over PFA insulation, providing superior dielectric bond. This standard part features a conductor gauge of 29 AWG, silver-plated copper conductor material, and a voltage rating of 3 kVDC. With an operating temperature range of -55 to 125°C, this cable ensures durability and performance in various settings, meeting the highest standards of quality and reliability for high voltage applications.

Product Specifications

Alternate Cable Part Number Equivalents Etched Part Number

178-5133

Cable Wire Properties Etched

Cable Wire Properties Jacketed

Cable Wire Properties Silicone Coated

Yes

Cable Wire Properties Twisted Pair

Cable Wire Properties Twisted Shielded Pair

Options Optional Color

Specifications Conductor Diameter

0.012 in | 0.33 mm

Specifications Conductor Gauge

29 AWG

Specifications Conductor Material

Copper

Specifications Conductor Plating

Silver Plated

Specifications Conductor Strands

51/46

Specifications Default Color

Natural

Specifications Diameter Over Silicon Coating

0.029 in | 0.79 mm

Specifications Insulator Material

PFA

Specifications Operating Temperature

-55 to 125 ÂºC

Specifications Overall Diameter

0.029 in

Specifications Standardnon Standard

Standard Part

Specifications Voltage Rating

3 kVDC

Specifications Wire Type

Non-Shielded

Silicone Coated High Voltage Microflex - 3kVDC Wire & Cable
