Silicone-Coated High Voltage Microflex Cable
Silicone-Coated High Voltage Microflex Cable
SKU:HIG-731bff
High Voltage Microflex Cable with Silicone Coating, enhanced safety & performance in extreme conditions.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Silicone-Coated High Voltage Microflex Cable
$29.99
Quantity: 1
Claim Your Seller Account
Silicone-Coated High Voltage Microflex Cable
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Silicone-Coated High Voltage Microflex Cable is expertly designed for high voltage applications, featuring PFA insulation with a durable silicone rubber coating. With a superior dielectric bond, this cable ensures reliable performance even in challenging environments. Operating temperature ranges from -55 to +125 °C, making it ideal for a wide range of industrial and institutional uses.
Product Specifications
Alternate Cable Part Number Equivalents Etched Part Number
178-5139
Cable Wire Properties Etched
No
Cable Wire Properties Jacketed
No
Cable Wire Properties Silicone Coated
Yes
Cable Wire Properties Twisted Pair
No
Cable Wire Properties Twisted Shielded Pair
No
Options Optional Color
Black | Blue | Brown | Green | Grey | Orange | Red | Violet | White | Yellow
Specifications Conductor Diameter
0.014 in | 0.37 mm
Specifications Conductor Gauge
28 AWG
Specifications Conductor Material
Copper
Specifications Conductor Plating
Silver Plated
Specifications Conductor Strands
41/44
Specifications Default Color
Natural
Specifications Diameter Over Silicon Coating
0.052 in | 1.32 mm
Specifications Insulator Material
PFA
Specifications Operating Temperature
-55 to 125 ºC
Specifications Overall Diameter
0.052 in
Specifications Standardnon Standard
Standard Part
Specifications Voltage Rating
13.5 kVDC
Specifications Wire Type
Non-Shielded
