Single Horizontal Sheave Assembly - 6000 lbs. Capacity
Single Horizontal Sheave Assembly - 6000 lbs. Capacity
SKU:RIG-92c700
Highly durable Single Horizontal Sheave Assembly for heavy-duty lifting and pulling with 6000 lbs. capacity. Versatile mounting options.
Regular price
$399.99
Regular price
Sale price
$399.99
Unit price
per
Initiate Order
Single Horizontal Sheave Assembly - 6000 lbs. Capacity
$399.99
Quantity: 1
Claim Your Seller Account
Single Horizontal Sheave Assembly - 6000 lbs. Capacity
$399.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Single Horizontal Sheave Assembly is a robust and reliable solution designed for heavy-duty lifting and pulling applications. With a capacity of 6000 lbs. and a wire rope diameter of 1/2 inches, this assembly excels in durability and functionality. Featuring dimensions carefully crafted for optimal performance, this assembly ensures efficient operation. Equipped with essential controls like Lever Drum Mounted at Winch and Magnetic Remote Pushbutton, it offers versatility in use. Mountable horizontally, inverted on the ceiling, or vertically, this assembly caters to diverse mounting needs in various settings.
Product Specifications
Specifications Capacity
6000 lbs.
Specifications Controls
Lever Drum Mounted at Winch | Magnetic Remote Pushbutton
Specifications Dimension A
17 inches
Specifications Dimension B
15 inches
Specifications Dimension C
8 1/2 inches
Specifications Dimension D
4 3/4 inches
Specifications Dimension E
2 inches
Specifications Dimension F
5 3/8 inches
Specifications Dimension G
3/4 inches
Specifications Dimension H
1 inches
Specifications Model
SHS
Specifications Mounting
Horizontal Base | Inverted Ceiling | Vertical
Specifications Pitch Diameter
8 inches
Specifications Winch Will Be Used For
Electrical Brake Required | Lifting | Pulling
Specifications Wire Rope Diameter
1/2 inches
