Single Pass Full Color High Resolution Inkjet Printing System
Single Pass Full Color High Resolution Inkjet Printing System
SKU:SIN-c497b4
Achieve precision and speed with the Single Pass Full Color High Resolution Inkjet Printing System. High-quality prints at 180 dpi vertical resolution.
Regular price
$14,999.99
Regular price
Sale price
$14,999.99
Unit price
per
Initiate Order
Single Pass Full Color High Resolution Inkjet Printing System
$14,999.99
Quantity: 1
Claim Your Seller Account
Single Pass Full Color High Resolution Inkjet Printing System
$14,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Single Pass Full Color High Resolution Inkjet Printing System offers impeccable vertical print resolution of 180 dpi and horizontal resolution of 1,800 dpi, ensuring crisp and vibrant prints. With a remarkable print speed of 1,000 fpm, this system is perfect for high-volume printing needs. It supports CMYK with Spot Colors, prints on various substrates, and allows for flexible print orientation. Benefit from its ease of use, fast data transfer, and seamless integration with ERP systems.
Product Specifications
Advantages Advantages
Easy message creationMessage height in increments of 4.25"No limit on number of headsPrints from software that can render imagesEvery message can be differentUltra fast data transfer timesEthernet connectionConnect with any ERPControlled from a PC or tablet no controller needed
Benefits Benefits
Print On DemandShort or Long RunsFlexibilitySKU ReductionObsolescence ReductionTool Cost Reduction
Communications Comm Protocol
Several comm protocols are supported Ethernet
Communications External Database
Per Storage Capacity
Communications Remote Assist
Yes
Electrical Frequency
50 Hz | 60 Hz
Electrical Power Supply Alternating Current Ac Voltage
110 to 240 V
Electrical Power Supply Phase
Single
Electronics Comm Ports
1 Trigger Input | 2 USB Ethernet) | 8 Configurable Inputs | 8 Configurable Outputs | Ethernet (2 RS232 | Universal Serial Bus (USB)
Electronics Inputs
Per ink/control system which can handle 2 colors.
Electronics Outputs
2 encoder
Environment Non Condensing Relative Humidity
90 %
Environment Operating Temperature
5 to 40 ºC | 40 to 110 ºF
Optional Alarm Beacons Customizations Of Systems Integrations
Per Customer Request
Optional Vision System
Any brand
Printer Font Types
True Type Fonts
Printer Ingress Protection Ip Rating
Currently not limited | Ink Supply - Ingress Protection (IP42) | Other IPs Available | Printhead - Ingress Protection (IP42)
Printer Print Colors
CMYK W Spot Colors
Printer Print Height
Increments of 4.25 in
Printer Print Length
No limit
Printer Print Orientation
360 (Side, Down and Up)
Printer Print Substrates
Non-Porous | Porous
Technical Specs Barcodes
All available
Technical Specs Horizontal Print Resolution
1,800 dpi
Technical Specs Print Speed
1,000 fpm
Technical Specs Vertical Print Resolution
180 dpi
User Interface Controller
PC-Tablet-Smart Phone
User Interface Message Editor
Embedded Any software that can render an image
User Interface Variable Data Fields
No limit
