SINPAC IR Series Instant Reverse Switch for Motor Reversal
SINPAC IR Series Instant Reverse Switch for Motor Reversal
SKU:MOT-0f8168
Enhance motor control with instant direction changes, UL recognized and CSA certified.
Regular price
$180.87
Regular price
Sale price
$180.87
Unit price
per
Initiate Order
SINPAC IR Series Instant Reverse Switch for Motor Reversal
$180.87
Quantity: 1
Claim Your Seller Account
SINPAC IR Series Instant Reverse Switch for Motor Reversal
$180.87
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your motor performance with the SINPAC IR Series Instant Reverse Switch, featuring seamless direction changes without time delay. This innovative switch transforms reversible motors into instant reversing motors, enhancing efficiency and control. With UL recognition, CSA certification, and solid-state technology, it ensures reliable operation and durability. Operates between -40°C to 65°C with silent operation and no switch noise. Increase productivity with this versatile solution that meets institutional procurement standards.
Product Specifications
Additional Features Additional Features
UL recognition and CSA certification. Completely solid-state with no moving parts. SINPAC Switches have no physical constraints to affect their operation. No wearing parts mean high cycling, no arcing contact. Low warranty Silent operation - no switch noise Operating Temperature: -40°C to 65 °C (-40 °F to 149°F) [for operation between 65°C and 85°C (149°F and 185°F), consult factory.] Operating Voltage: 115 Vac SINPAC Switch: 90-130 Vac. For dual voltage motor equipped with center-tapped main winding: 90-130 Vac or 180-265 Vac.
Specifications Cut In Voltage
37 V
Specifications Cut Out Voltage
165 V
Specifications Kit Part Number
4-7-51040-15-UO1
Specifications List Price
180.87 USD
Specifications Manufacturer
Stearns® SINPAC®
Specifications Package Style
15
Specifications Start Winding Voltage
115 V
Specifications Switch Rating And Permissible Maximum Start Windi
40 A
Specifications Full Load Motor Nameplate Current Rating
10 A
Specifications Maximum Motor Hp
2
