SK 2.9mm Panel Launchers - Female Jack Connectors

Name: SK 2.9mm Panel Launchers - Female Jack Connectors
Brand: C. W. Swift & Associates, Inc.
SKU: SK2-81a113
Price: 29.99 USD
Availability: OutOfStock

SKU:SK2-81a113

Enhance your communication setups with our durable SK 2.9mm Panel Launchers for precision connectivity.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Upgrade your communication systems with the SK 2.9mm Panel Launchers featuring Series PC 3.5 precision subminiature launchers. Designed to meet the stringent requirements of institutional and government procurement, these connectors offer an impedance of 50 Ohms, frequency range up to 40GHz, and durability of over 500 matings. Crafted from beryllium-copper hardened material, they ensure high performance in a wide temperature range (-67 to 257°F) while meeting industry-specific certifications.

Product Specifications

Specifications Body Material

beryllium-copper hardened

Specifications Centre Contacts

beryllium-copper hardened

Specifications Centre Contact Resistance M Ohms

Specifications Configuration

panel

Specifications Connection

female

Specifications Connector Series

Specifications Contact Captivation Lbs

>4.9

Specifications Dielectic Withstanding Voltage Sea Level V Rms

750

Specifications Durability Matings

>500

Specifications Flange Type

2-hole

Specifications Frequency Ghz

DC...40

Specifications Impedance Ohms

Specifications Insulation Resistance M Ohms

>5000

Specifications Mounting Hole

ML 78

Specifications Outside Contact Resistance M Ohms

Specifications Packaging

single

Specifications Support Beads

PPO

Specifications Temperature Range Degrees F

-67 to 257

Specifications Working Voltage Sea Level V Rms

<250

SK 2.9mm Panel Launchers - Female Jack Connectors
