SK (2.9MM) Precision Plug-to-Plug Adaptors

Name: SK (2.9MM) Precision Plug-to-Plug Adaptors
Brand: C. W. Swift & Associates, Inc.
SKU: SK2-a18b31
Price: 29.99 USD
Availability: OutOfStock

SKU:SK2-a18b31

Enhance connections with our high-quality SK Series 2.9MM Plug-to-Plug Adaptors. Ideal for up to 40 GHz frequency with 50 Ohms impedance.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Upgrade your precision connections with our SK Series 2.9MM Plug-to-Plug Adaptors. Designed for impedance of 50 Ohms, frequency up to 40 GHz, and featuring a durable beryllium-copper construction, these adaptors ensure optimal signal integrity. With compliance to industry standards like IEEE and MIL-STD, these adaptors guarantee reliable performance in demanding environments.

Product Specifications

Specifications Body Material

beryllium-copper hardened

Specifications Centre Contacts

beryllium-copper hardened

Specifications Centre Contact Resistance M Ohms

Specifications Configuration

straight

Specifications Connection

male-male

Specifications Connector Series

Specifications Contact Captivation Lbs

>4.9

Specifications Dielectic Withstanding Voltage Sea Level V Rms

750

Specifications Durability Matings

>500

Specifications Frequency Ghz

DC...40

Specifications Impedance Ohms

Specifications Insulation Resistance M Ohms

>5000

Specifications Outside Contact Resistance M Ohms

Specifications Packaging

single

Specifications Support Beads

PPO

Specifications Temperature Range Degrees F

-67 to 257

Specifications Vswr Dc 40 Ghz F

<1.20

Specifications Working Voltage Sea Level V Rms

<250
