SK 2.9MM Precision Subminiature Connector Launchers (Female)

Name: SK 2.9MM Precision Subminiature Connector Launchers (Female)
Brand: C. W. Swift & Associates, Inc.
SKU: SK2-1cb390
Price: 79.99 USD
Availability: OutOfStock

SKU:SK2-1cb390

SK 2.9MM Precision Subminiature Connector Launchers (Female) - Ideal for institutional connectivity needs

$79.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Upgrade your connectivity with the SK 2.9MM Precision Subminiature Connector Launchers (Female). Designed to meet the strict impedance, frequency, and durability requirements of institutional and government applications. With an impedance of 50 Ohms, frequency range up to 40GHz, hardened beryllium-copper construction for robustness, and insulation resistance exceeding 5000 M ohms, this launcher ensures reliable performance in challenging environments. Compliant with Federal/DoD procurement standards, GSA requirements, and FAR compliance factors.

Product Specifications

Specifications Body Material

beryllium-copper hardened

Specifications Centre Contacts

beryllium-copper hardened

Specifications Centre Contact Resistance M Ohms

Specifications Configuration

straight

Specifications Connection

female

Specifications Connector Series

Specifications Contact Captivation Lbs

>4.9

Specifications Dielectic Withstanding Voltage Sea Level V Rms

750

Specifications Durability Matings

>500

Specifications Frequency Ghz

DC...40

Specifications Impedance Ohms

Specifications Insulation Resistance M Ohms

>5000

Specifications Mounting Hole

ML 75

Specifications Outside Contact Resistance M Ohms

Specifications Packaging

single

Specifications Support Beads

PPO

Specifications Temperature Range Degrees F

-67 to 257

Specifications Working Voltage Sea Level V Rms

<250
