SK 2.9MM Precision Subminiature Launchers, Male Plug

Name: SK 2.9MM Precision Subminiature Launchers, Male Plug
Brand: C. W. Swift & Associates, Inc.
SKU: SK2-c529eb
Price: 29.99 USD
Availability: OutOfStock

SKU:SK2-c529eb

SK 2.9MM Precision Subminiature Launchers, Male Plug - High-performance connectors for precise signal transmission in extreme conditions.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The SK 2.9MM Precision Subminiature Launchers are designed to meet the demanding requirements of high-frequency applications. With an impedance of 50 Ohms and a frequency range from DC to 40GHz, these launchers ensure reliable signal transmission. Built with beryllium-copper hardened material for both the body and center contacts, they offer exceptional durability with over 500 matings. Meeting insulation resistance of over 5000 M ohms, these connectors are ideal for applications requiring high reliability in extreme temperatures from -67 to 257 degrees F. Each launcher is meticulously engineered to exceed industry standards, making it a top choice for professionals in RF communications.

Product Specifications

Specifications Body Material

beryllium-copper hardened

Specifications Centre Contacts

beryllium-copper hardened

Specifications Centre Contact Resistance M Ohms

Specifications Configuration

straight

Specifications Connection

male

Specifications Connector Series

Specifications Contact Captivation Lbs

>4.9

Specifications Dielectic Withstanding Voltage Sea Level V Rms

750

Specifications Durability Matings

>500

Specifications Frequency Ghz

DC...40

Specifications Impedance Ohms

Specifications Insulation Resistance M Ohms

>5000

Specifications Mounting Hole

ML 75

Specifications Outside Contact Resistance M Ohms

Specifications Packaging

single

Specifications Support Beads

PPO

Specifications Temperature Range Degrees F

-67 to 257

Specifications Working Voltage Sea Level V Rms

<250

SK 2.9MM Precision Subminiature Launchers, Male Plug
