SK 2.9mm Precision Subminiature Panel Launchers (Female)

Name: SK 2.9mm Precision Subminiature Panel Launchers (Female)
Brand: C. W. Swift & Associates, Inc.
SKU: SK2-049901
Price: 59.99 USD
Availability: OutOfStock

SKU:SK2-049901

High-performance SK 2.9mm female panel launcher for precision connections in institutional setups. Impedance: 50 Ohms, Frequency: up to 40GHz. Durable and compliant.

$59.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Experience high-quality connectivity with the SK 2.9mm Precision Subminiature Panel Launchers. Featuring an impedance of 50 Ohms, frequency range up to 40GHz, and beryllium-copper construction, these launchers ensure reliable performance in demanding environments. With compliance to stringent industry standards and durability exceeding 500 matings, they are ideal for institutional and government applications.

Product Specifications

Specifications Body Material

beryllium-copper hardened

Specifications Centre Contacts

beryllium-copper hardened

Specifications Centre Contact Resistance M Ohms

Specifications Configuration

panel

Specifications Connection

female

Specifications Connector Series

Specifications Contact Captivation Lbs

>4.9

Specifications Dielectic Withstanding Voltage Sea Level V Rms

750

Specifications Durability Matings

>500

Specifications Flange Type

2-hole

Specifications Frequency Ghz

DC...40

Specifications Impedance Ohms

Specifications Insulation Resistance M Ohms

>5000

Specifications Mounting Hole

ML 78

Specifications Outside Contact Resistance M Ohms

Specifications Packaging

single

Specifications Support Beads

PPO

Specifications Temperature Range Degrees F

-67 to 257

Specifications Working Voltage Sea Level V Rms

<250

SK 2.9mm Precision Subminiature Panel Launchers (Female)
