SK (2.9MM) Precision Subminiature Panel Launchers, Jack (Female)

Name: SK (2.9MM) Precision Subminiature Panel Launchers, Jack (Female)
Brand: C. W. Swift & Associates, Inc.
SKU: SK2-dfbcdf
Price: 29.99 USD
Availability: OutOfStock

SKU:SK2-dfbcdf

Upgrade with SK (2.9MM) Precision Subminiature Panel Launchers for reliable connectivity. Impedance: 50 Ohms, Frequency: DC...40 GHz, Durability: >500 matings.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Enhance your connectivity with the SK (2.9MM) Precision Subminiature Panel Launchers. These female connectors feature a durable design with beryllium-copper hardened body material, ensuring high-performance and reliability in challenging environments. With an impedance of 50 Ohms, frequency up to 40 GHz, and a wide temperature range from -67 to 257 degrees F, these connectors are built to excel in demanding applications. Meeting strict industry standards for impedance, voltage withstand, and contact resistance, these launchers offer over 500 matings, exceeding durability expectations.

Product Specifications

Specifications Body Material

beryllium-copper hardened

Specifications Centre Contacts

beryllium-copper hardened

Specifications Centre Contact Resistance M Ohms

Specifications Configuration

panel

Specifications Connection

female

Specifications Connector Series

Specifications Contact Captivation Lbs

>4.9

Specifications Dielectic Withstanding Voltage Sea Level V Rms

750

Specifications Durability Matings

>500

Specifications Flange Type

square

Specifications Frequency Ghz

DC...40

Specifications Impedance Ohms

Specifications Insulation Resistance M Ohms

>5000

Specifications Mounting Hole

ML 77

Specifications Outside Contact Resistance M Ohms

Specifications Packaging

single

Specifications Support Beads

PPO

Specifications Temperature Range Degrees F

-67 to 257

Specifications Working Voltage Sea Level V Rms

<250

SK (2.9MM) Precision Subminiature Panel Launchers, Jack (Female)
