SMA Female Jack Receptacle with Solder End
SMA Female Jack Receptacle with Solder End
SKU:SMA-beee3f
High-quality SMA Female Jack Receptacle with solder end for reliable and cost-effective connectivity solutions.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
SMA Female Jack Receptacle with Solder End
$89.99
Quantity: 1
Claim Your Seller Account
SMA Female Jack Receptacle with Solder End
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The SMA Female Jack Receptacle with Solder End is designed for high-performance applications, featuring a gold-plated body, 50 ohms impedance, and a frequency range of up to 18 GHz. This rear mounting, panel mount receptacle comes in a bulk pack of 100 pieces, ensuring cost-effective connectivity solutions. Meet your SMA connector needs with reliability and precision.
Product Specifications
Specifications Cable Dielectic Dia Inches
.066/.117
Specifications Configuration
rear mounting, panel mount receptacle
Specifications Connection
female
Specifications Connector Series
SMA
Specifications Frequency Range Ghz
DC - 18
Specifications Impedence Ohms
50
Specifications Mounting Hole
ML 35
Specifications Packaging
bulk 100 pcs.
Specifications Plating Body
gold
