SMA Female Jack Receptacles with Solder End
SMA Female Jack Receptacles with Solder End
SKU:SMA-f1eb1a
High-performance SMA Female Jack Receptacles for up to 18GHz frequency range, stainless steel body, 50 ohm impedance.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
SMA Female Jack Receptacles with Solder End
$24.99
Quantity: 1
Claim Your Seller Account
SMA Female Jack Receptacles with Solder End
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The SMA Female Jack Receptacles with Solder End are precision-engineered connectors designed for high-frequency applications up to 18GHz. Featuring a stainless steel body for durability, these panel mount receptacles ensure optimal signal transmission. With an impedance of 50 ohms, they meet strict SMA connector series standards. Ideal for institutional procurement, these receptacles are single-packaged and compatible with cable dielectrics ranging from .066 to .117 inches.
Product Specifications
Specifications Cable Dielectic Dia Inches
.066/.117
Specifications Configuration
panel mount receptacle
Specifications Connection
female
Specifications Connector Series
SMA
Specifications Frequency Range Ghz
DC - 18
Specifications Impedence Ohms
50
Specifications Packaging
single
Specifications Plating Body
stainless steel
