SMA Female Microstrip Panel Launchers
SMA Female Microstrip Panel Launchers
SKU:SMA-a70805
High-performance SMA Female Microstrip Panel Launchers for DC-18GHz frequency range, optimal conductivity, and flush dielectric. Reliable & durable.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
SMA Female Microstrip Panel Launchers
$24.99
Quantity: 1
Claim Your Seller Account
SMA Female Microstrip Panel Launchers
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The SMA Female Microstrip Panel Launchers are precision-engineered for high-performance applications, featuring a frequency range of DC-18GHz, 50 ohms impedance, and gold-plated body for optimal conductivity. Ideal for SMA Stripline deployments, they ensure seamless connections with a flush dielectric design. Built to exceed industry standards, these microstrip launchers deliver reliability and durability in every use.
Product Specifications
Specifications Cable Dielectic Dia Inches
.066/.117
Specifications Configuration
microstrip launcher
Specifications Connection
female
Specifications Connector Series
SMA
Specifications Frequency Range Ghz
DC - 18
Specifications Impedence Ohms
50
Specifications Notes
flush dielectic
Specifications Packaging
single
Specifications Plating Body
gold
