SMA Female Straight PCB Jacks

Name: SMA Female Straight PCB Jacks
Brand: C. W. Swift & Associates, Inc.
SKU: SMA-b01097
Price: 49.99 USD
Availability: OutOfStock

SKU:SMA-b01097

Premium SMA Female PCB Jacks for reliable signal transmission. Gold-plated, bulk packaging of 100 pcs. Ideal for professional applications.

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The SMA Female Straight PCB Jacks are precision-engineered for superior performance. With a cable dielectric dia. of .066/.117 inches, 50 ohms impedance, and a frequency range of DC - 18 GHz, these connectors ensure reliable signal transmission. Featuring gold plating, a straight PCB jack configuration, and bulk packaging of 100 pcs., they offer durability and convenience. Compliant with SMA connector series standards, these jacks are ideal for applications requiring a secure female connection. Mounting hole ML 41 allows for easy installation, making them suitable for a range of professional uses.

Product Specifications

Specifications Cable Dielectic Dia Inches

.066/.117

Specifications Configuration

straight PCB jack

Specifications Connection

female

Specifications Connector Series

SMA

Specifications Frequency Range Ghz

DC - 18

Specifications Impedence Ohms

Specifications Mounting Hole

ML 41

Specifications Packaging

bulk 100 pcs.

Specifications Plating Body

gold

SMA Female Straight PCB Jacks
