SMA Receptacles with Solder End, Female Jack Connector
SMA Receptacles with Solder End, Female Jack Connector
SKU:SMA-48dc41
High-quality SMA receptacles with solder end, female jack connector for secure connections in high-performance applications.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
SMA Receptacles with Solder End, Female Jack Connector
$24.99
Quantity: 1
Claim Your Seller Account
SMA Receptacles with Solder End, Female Jack Connector
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The SMA Receptacles with Solder End, Female Jack Connector are designed for high-performance applications requiring a reliable and secure connection. With a cable dielectric dia. of .066/.117 inches, 50-ohm impedance, and a frequency range of DC - 18 GHz, these connectors ensure excellent signal integrity. The rear mounting, panel mount receptacle configuration with SUCOPLATE plating offers durability and ease of installation. Ideal for institutional and government use due to compliance with Federal/DoD procurement standards, GSA requirements, FAR compliance factors, DLA standards, and NIST standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Cable Dielectic Dia Inches
.066/.117
Specifications Configuration
rear mounting, panel mount receptacle
Specifications Connection
female
Specifications Connector Series
SMA
Specifications Frequency Range Ghz
DC - 18
Specifications Impedence Ohms
50
Specifications Mounting Hole
ML 35
Specifications Packaging
single
Specifications Plating Body
SUCOPLATE
