The Song Chuan 210 Photovoltaic (PV) Relay is engineered for superior performance in charger applications. With a compact design measuring 29mm x 12.5mm x 25.1mm, this relay offers a contact configuration of 2A and can withstand a maximum allowable contact current of 16A. It features a contact rating of 12A for resistive load at 250V AC voltage, ensuring reliable operation. Additionally, this relay meets stringent safety approvals from both the Association of Electrical Engineering (VDE) and Underwriters Laboratories (UL), guaranteeing compliance with industry standards.
Product Specifications
Specifications Ac Dielectric Strength Between Contact And Coil
5000 V
Specifications Ac Dielectric Strength Between Contact Circuits
2500 V
Specifications Ac Dielectric Strength Between Open Contact
1500 V
Specifications Contact Configuration
2A
Specifications Contact Gap
1.85 mm | 2.1 mm
Specifications Contact Rating Resistive Load At 250 Volts V Ac V
12 A
Specifications Dc Coil Voltage
12 to 24 V
Specifications Dc Holding Power Consumption
0.29 W
Specifications Dc Power Consumption
1.4 W
Specifications Electrical Life Expectancy
3 x 104 min
Specifications Maximum Allowable Contact Current
16 A
Specifications Mechanical Life Expectancy
1 x 105 min
Specifications Outline Height
25.1 mm
Specifications Outline Length
29 mm
Specifications Outline Width
12.5 mm
Specifications Safety Approval
Association of Electrical Engineering (VDE) | Underwriters Laboratories (UL)
