Song Chuan 30A DC Switch Relay for Charger Applications
Song Chuan 30A DC Switch Relay for Charger Applications
SKU:SON-599d81
Reliable Song Chuan 30A DC Switch Relay for Charger Applications with UL Safety Approval
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Song Chuan 30A DC Switch Relay for Charger Applications
$29.99
Quantity: 1
Claim Your Seller Account
Song Chuan 30A DC Switch Relay for Charger Applications
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Song Chuan 30A DC Switch Relay is a high-quality solution designed for charger applications. With a compact outline of 35.3mm x 31.6mm x 33.5mm, this relay offers a contact configuration of 1A, allowing a maximum allowable contact current of 30A at 400V DC voltage. It boasts a durable design with a mechanical life expectancy of 5 x 10^5 minutes and complies with safety standards set by Underwriters Laboratories (UL). Ideal for various institutional and government procurement needs, this relay ensures reliable performance and efficient power consumption.
Product Specifications
Specifications Ac Dielectric Strength Between Contact And Coil
2500 V
Specifications Ac Dielectric Strength Between Open Contact
2000 V
Specifications Contact Configuration
1A
Specifications Contact Rating Resistive Load At 400 Volt V Dc Vo
30 A
Specifications Dc Coil Voltage
12 to 24 V
Specifications Dc Holding Power Consumption
0.36 W
Specifications Dc Power Consumption
1.8 W
Specifications Electrical Life Expectancy
5 x 103 min
Specifications Maximum Allowable Contact Current
30 A
Specifications Mechanical Life Expectancy
5 x 105 min
Specifications Outline Height
33.5 mm
Specifications Outline Length
35.3 mm
Specifications Outline Width
31.6 mm
Specifications Safety Approval
Underwriters Laboratories (UL)
