Song Chuan 40A DC Switch Relay for Charger Application
Song Chuan 40A DC Switch Relay for Charger Application
SKU:SON-18188e
Reliable 40A DC Switch Relay for Charger Applications, UL Safety Approved
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Song Chuan 40A DC Switch Relay for Charger Application
$39.99
Quantity: 1
Claim Your Seller Account
Song Chuan 40A DC Switch Relay for Charger Application
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Song Chuan 40A DC Switch Relay is a high-performance solution designed for charger applications. With a compact outline of 35.3mm x 31.6mm x 33.5mm, this relay offers a contact configuration of 1A and a maximum allowable contact current of 40A. It operates at a DC coil voltage range of 12 to 24V, consuming only 1.8W power during operation. With safety approval from Underwriters Laboratories (UL), this relay ensures reliability and efficiency for your charging systems. It meets stringent mechanical and electrical life expectancy standards, making it ideal for both consumer and institutional procurement needs.
Product Specifications
Specifications Ac Dielectric Strength Between Contact And Coil
2500 V
Specifications Ac Dielectric Strength Between Open Contact
2000 V
Specifications Contact Configuration
1A
Specifications Contact Rating Resistive Load At 400 Volt V Dc Vo
40 A
Specifications Dc Coil Voltage
12 to 24 V
Specifications Dc Holding Power Consumption
0.36 W
Specifications Dc Power Consumption
1.8 W
Specifications Electrical Life Expectancy
5 x 103 min
Specifications Maximum Allowable Contact Current
40 A
Specifications Mechanical Life Expectancy
5 x 105 min
Specifications Outline Height
33.5 mm
Specifications Outline Length
35.3 mm
Specifications Outline Width
31.6 mm
Specifications Safety Approval
Underwriters Laboratories (UL)
