Song Chuan 510C PV Relay for Charger, 50A, 12-24V DC Coil
Song Chuan 510C PV Relay for Charger, 50A, 12-24V DC Coil
SKU:SON-205cf2
Reliable Song Chuan 510C PV Relay for Charger, 50A, 12-24V DC Coil. Safety approved & durable.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Song Chuan 510C PV Relay for Charger, 50A, 12-24V DC Coil
$24.99
Quantity: 1
Claim Your Seller Account
Song Chuan 510C PV Relay for Charger, 50A, 12-24V DC Coil
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Song Chuan 510C Photovoltaic (PV) Relay is a reliable solution designed for charger applications, featuring a contact configuration of 2A suitable for handling up to a maximum allowable contact current of 50A. With resistive load contact ratings at various AC voltages and a DC coil voltage range of 12-24V, this relay ensures efficient performance and durability. Meeting safety approvals from TUV and UL, this relay offers a mechanical life expectancy of 1 x 10^6 min and electrical life expectancy meeting industry standards. Ideal for institutional and government procurement needs.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Ac Dielectric Strength Between Contact And Coil
4000 V
Specifications Ac Dielectric Strength Between Contact Circuits
2000 V
Specifications Ac Dielectric Strength Between Open Contact
2000 V
Specifications Contact Configuration
2A
Specifications Contact Gap
2.1 mm | 3.0 mm
Specifications Contact Rating Resistive Load At 240 Volts V Ac V
50 A
Specifications Contact Rating Resistive Load Breaking At 400 Vol
20 A
Specifications Contact Rating Resistive Load Carrying At 400 Vol
50 A
Specifications Contact Rating Resistive Load Making At 400 Volts
20 A
Specifications Dc Coil Voltage
12 to 24 V
Specifications Dc Holding Power Consumption
1.35 W
Specifications Dc Power Consumption
5.4 W
Specifications Electrical Life Expectancy
3 x 104 min | 6 x 103 min
Specifications Maximum Allowable Contact Current
50 A
Specifications Mechanical Life Expectancy
1 x 106 min
Specifications Outline Height
38.8 mm
Specifications Outline Length
51.5 mm
Specifications Outline Width
34.75 mm
Specifications Safety Approval
Association for Technical Inspection (TUV) | Underwriters Laboratories (UL)
