Song Chuan High Voltage Relay HV015
Song Chuan High Voltage Relay HV015
SKU:SON-536e57
Reliable Song Chuan High Voltage Relay with 1A contact configuration and 40A maximum current at 400V DC. Ideal for high voltage circuit control.
Regular price
$35.99
Regular price
Sale price
$35.99
Unit price
per
Initiate Order
Song Chuan High Voltage Relay HV015
$35.99
Quantity: 1
Claim Your Seller Account
Song Chuan High Voltage Relay HV015
$35.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Song Chuan HV015 High Voltage Relay is a reliable and efficient solution for controlling high voltage circuits. With a compact design measuring 35.3mm x 31.6mm x 32mm, this relay features a contact configuration of 1A and a maximum allowable contact current of 40A at 400 Volts DC. The DC coil voltage ranges from 12 to 24V, ensuring flexibility in various applications. With a mechanical life expectancy of 5 x 10^5 min and electrical life expectancy of 5 x 10^3 min, this high voltage relay offers long-lasting performance. The AC dielectric strength between open contact and contact and coil meets industry standards at 2000V and 2500V respectively.
Product Specifications
Specifications Ac Dielectric Strength Between Contact And Coil
2500 V
Specifications Ac Dielectric Strength Between Open Contact
2000 V
Specifications Contact Configuration
1A
Specifications Contact Rating Resistive Load At 400 Volts V Dc V
40 A
Specifications Dc Coil Voltage
12 to 24 V
Specifications Dc Holding Power Consumption
0.36 W
Specifications Dc Power Consumption
1.8 W
Specifications Electrical Life Expectancy
5 x 103 min
Specifications Maximum Allowable Contact Current
40
Specifications Mechanical Life Expectancy
5 x 105 min
Specifications Outline Height
32 mm
Specifications Outline Length
35.3 mm
Specifications Outline Width
31.6 mm
