Song Chuan HV013 High Voltage Relay
Song Chuan HV013 High Voltage Relay
SKU:SON-9227bc
Reliable Song Chuan HV013 High Voltage Relay for consumer and institutional applications. 1A, 30A, 400V DC, compact design.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Song Chuan HV013 High Voltage Relay
$24.99
Quantity: 1
Claim Your Seller Account
Song Chuan HV013 High Voltage Relay
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Song Chuan HV013 High Voltage Relay is a reliable and efficient solution for high-voltage applications. With a compact outline measuring 35.3mm x 31.6mm x 32mm, this relay features a 1A contact configuration and a maximum allowable contact current of 30A at 400 Volts DC. Designed for durability, it offers a mechanical life expectancy of 5 x 10^5 minutes and an electrical life expectancy of 1 x 10^4 minutes. Its AC dielectric strength of 2000V between open contacts and 2500V between contact and coil ensures safety and performance. Perfect for both consumer and institutional buyers, the Song Chuan HV013 meets stringent industry standards for quality and reliability.
Product Specifications
Specifications Ac Dielectric Strength Between Contact And Coil
2500 V
Specifications Ac Dielectric Strength Between Open Contact
2000 V
Specifications Contact Configuration
1A
Specifications Contact Rating Resistive Load At 400 Volts V Dc V
30 A
Specifications Dc Coil Voltage
12 to 24 V
Specifications Dc Power Consumption
1.25 W
Specifications Electrical Life Expectancy
1 x 104 min
Specifications Maximum Allowable Contact Current
30
Specifications Mechanical Life Expectancy
5 x 105 min
Specifications Outline Height
32 mm
Specifications Outline Length
35.3 mm
Specifications Outline Width
31.6 mm
