Song Chuan MV023 Middle Voltage Relay
Song Chuan MV023 Middle Voltage Relay
SKU:SON-4ccdb9
Reliable Song Chuan MV023 Middle Voltage Relay, 150A max current, 12-48V DC coil, durable design for long-term use.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Song Chuan MV023 Middle Voltage Relay
$29.99
Quantity: 1
Claim Your Seller Account
Song Chuan MV023 Middle Voltage Relay
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Song Chuan MV023 Middle Voltage Relay is a high-performance relay suitable for a wide range of applications. With a maximum allowable contact current of 150 A and a durable construction, this relay is designed for reliable and efficient operation. The DC coil voltage ranges from 12 to 48 V, with a low power consumption of 3.2 W. Meeting stringent industry standards for mechanical and electrical life expectancy, this relay ensures long-term performance and durability.
Product Specifications
Specifications Ac Dielectric Strength Between Contact And Coil
4000 V
Specifications Ac Dielectric Strength Between Open Contact
1000 V
Specifications Contact Configuration
1A
Specifications Contact Rating Resistive Load At 200 Volts V Dc V
150 A
Specifications Dc Coil Voltage
12 to 48 V
Specifications Dc Power Consumption
3.2 W
Specifications Electrical Life Expectancy
1 x 102 min
Specifications Maximum Allowable Contact Current
150 A
Specifications Mechanical Life Expectancy
1 x 106 min
Specifications Outline Height
46.5 mm
Specifications Outline Length
50 mm
Specifications Outline Width
41.5 mm
