The Song Chuan Photovoltaic (PV) Relay Model 510H is a high-quality relay designed for charger applications. With a robust construction meeting stringent industry standards, this relay offers a contact rating of 54A at 240V AC voltage, ensuring reliable performance under heavy loads. Its compact outline dimensions of 51.5mm x 34.75mm x 38.8mm make it ideal for space-constrained installations. The DC coil voltage range of 12 to 24V provides versatility in application, while safety approvals from TUV and UL guarantee compliance with essential safety regulations.
Product Specifications
Specifications Ac Dielectric Strength Between Contact And Coil
4000 V
Specifications Ac Dielectric Strength Between Contact Circuits
2000 V
Specifications Ac Dielectric Strength Between Open Contact
2000 V
Specifications Contact Configuration
2A
Specifications Contact Gap
2.1 mm | 3.0 mm
Specifications Contact Rating Resistive Load At 240 Volts V Ac V
54 A
Specifications Dc Coil Voltage
12 to 24 V
Specifications Dc Holding Power Consumption
1.35 W
Specifications Dc Power Consumption
5.4 W
Specifications Electrical Life Expectancy
1 x 104 min
Specifications Maximum Allowable Contact Current
54 A
Specifications Mechanical Life Expectancy
1 x 106 min
Specifications Outline Height
38.8 mm
Specifications Outline Length
51.5 mm
Specifications Outline Width
34.75 mm
Specifications Safety Approval
Association for Technical Inspection (TUV) | Underwriters Laboratories (UL)
