The Song Chuan PV Relay 207BX is a state-of-the-art solution designed for charger applications, boasting a contact configuration of 1C for reliable performance. With a maximum allowable contact current of 35A and robust contact ratings for resistive load at 240V AC Voltage, this relay ensures efficient power management. Its DC coil voltage range of 12 to 24V and low power consumption make it a cost-effective and energy-efficient choice. Meeting safety approvals from VDE and UL, this relay guarantees superior quality and compliance with industry standards.
Product Specifications
Specifications Ac Dielectric Strength Between Contact And Coil
4000 V
Specifications Ac Dielectric Strength Between Open Contact
1500 V
Specifications Contact Configuration
1C
Specifications Contact Rating Resistive Load Breaking At 240 Vol
8 A
Specifications Contact Rating Resistive Load Carrying At 240 Vol
32 A
Specifications Contact Rating Resistive Load Making At 240 Volts
8 A
Specifications Dc Coil Voltage
12 to 24 V
Specifications Dc Holding Power Consumption
0.19 W
Specifications Dc Power Consumption
1.67 W
Specifications Electrical Life Expectancy
1 x 104 min
Specifications Maximum Allowable Contact Current
35 A
Specifications Mechanical Life Expectancy
1 x 105 min
Specifications Outline Height
20.7 mm
Specifications Outline Length
21.5 mm
Specifications Outline Width
16 mm
Specifications Safety Approval
Association of Electrical Engineering (VDE) | Underwriters Laboratories (UL)
