Song Chuan PV Relay 207X for Charger Applications
Song Chuan PV Relay 207X for Charger Applications
SKU:SON-1963bb
High-performance Song Chuan PV Relay 207X for charger applications. Compact design, 35A max contact current, and VDE/UL safety approvals.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Song Chuan PV Relay 207X for Charger Applications
$29.99
Quantity: 1
Claim Your Seller Account
Song Chuan PV Relay 207X for Charger Applications
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Song Chuan PV Relay 207X is a high-performance relay designed for charger applications. With a compact outline measuring 21.5mm x 16mm x 20.7mm, this relay offers a contact configuration of 1A and a maximum allowable contact current of 35A. It features a contact rating resistive load of 25A to 35A at 240V AC voltage, making it ideal for demanding charging scenarios. This relay is meticulously crafted to meet the safety approvals of the Association of Electrical Engineering (VDE) and Underwriters Laboratories (UL), ensuring reliable operation in compliance with industry standards.
Product Specifications
Specifications Ac Dielectric Strength Between Contact And Coil
2500 V
Specifications Ac Dielectric Strength Between Open Contact
1000 V
Specifications Contact Configuration
1A
Specifications Contact Rating Resistive Load At 240 Volts V Ac V
25 A | 32 A | 35 A
Specifications Dc Coil Voltage
12 to 24 V
Specifications Dc Holding Power Consumption
0.29 W
Specifications Dc Power Consumption
2.8 W
Specifications Electrical Life Expectancy
1 x 104 min
Specifications Maximum Allowable Contact Current
35 A
Specifications Mechanical Life Expectancy
1 x 105 min
Specifications Outline Height
20.7 mm
Specifications Outline Length
21.5 mm
Specifications Outline Width
16 mm
Specifications Safety Approval
Association of Electrical Engineering (VDE) | Underwriters Laboratories (UL)
