Song Chuan PV Relay 210H for Charger Applications

Name: Song Chuan PV Relay 210H for Charger Applications
Brand: Marsh Electronics, Inc.
SKU: SON-e1338c
Price: 29.99 USD
Availability: OutOfStock

SKU:SON-e1338c

Reliable Song Chuan PV Relay 210H for chargers, with 16A contact rating, VDE/UL approvals & compact design.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Song Chuan PV Relay 210H is a top-of-the-line solution designed for charger applications in both consumer and institutional settings. With precise specifications including a contact rating of 16A, DC coil voltage range of 12-24V, and AC dielectric strengths meeting VDE and UL safety approvals, this relay ensures reliable performance under demanding conditions. Its compact outline of 29mm x 12.5mm x 25.1mm, coupled with a contact gap of 1.85mm-2.1mm, makes it ideal for space-constrained installations. Benefit from a mechanical life expectancy of 1 x 10^5 min, electrical life expectancy of 3 x 10^4 min, and minimal power consumption for enhanced efficiency.

Product Specifications

Specifications Ac Dielectric Strength Between Contact And Coil

5000 V

Specifications Ac Dielectric Strength Between Contact Circuits

2500 V

Specifications Ac Dielectric Strength Between Open Contact

1500 V

Specifications Contact Configuration

Specifications Contact Gap

1.85 mm | 2.1 mm

Specifications Contact Rating Resistive Load At 250 Volts V Ac V

14 A | 16 A

Specifications Dc Coil Voltage

12 to 24 V

Specifications Dc Holding Power Consumption

0.29 W

Specifications Dc Power Consumption

1.4 W

Specifications Electrical Life Expectancy

3 x 104 min

Specifications Maximum Allowable Contact Current

16 A

Specifications Mechanical Life Expectancy

1 x 105 min

Specifications Outline Height

25.1 mm

Specifications Outline Length

29 mm

Specifications Outline Width

12.5 mm

Specifications Safety Approval

Association of Electrical Engineering (VDE) | Underwriters Laboratories (UL)

Song Chuan PV Relay 210H for Charger Applications
