SpanTech SuperTight Santoprene 25mm Chain
SpanTech SuperTight Santoprene 25mm Chain
SKU:CHA-db5211
High-friction SpanTech Santoprene Chain for glossy finishes & containers. Durable, cost-effective, 25mm pitch, strong load capacity.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
SpanTech SuperTight Santoprene 25mm Chain
$89.99
Quantity: 1
Claim Your Seller Account
SpanTech SuperTight Santoprene 25mm Chain
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The SpanTech SuperTight Santoprene 25mm Chain is a high-friction chain with a weight of 1.9 lbs/ft² and a load carrying capacity of 50 lbs/ft². Ideal for glossy finishes, printed materials, and various containers, this chain features a tight turning radius, durable construction, and a cost-effective design. With a width range of 2.29 to 2.64 inches and a pitch size of 25mm, this chain offers both strength and versatility for a wide range of applications. Connected by 4mm stainless or mild steel rods and plastic tabs, it combines reliability with ease of maintenance.
Product Specifications
Chain Options Chain Options
Plain (White or Blue)6 mm Raised Top6 mm Moving Side Guide30 mm Moving Side Guide75 mm Moving Side GuidePlain High Friction6 mm Raised Top High Friction6 mm Brush Top High Friction10 mm Brush Top High Friction
Specifications Available Width Ranges
3.76 to 47.46 in | 95.5 to 1205.48 mm
Specifications Chain Weight
1.9 lb/ft²
Specifications Chain Width
2.29 to 2.64 in
Specifications Connecting Rod Material
Mild Steel | Stainless Steel
Specifications Connecting Rod Size
4 mm
Specifications Cost Effective
SuperTight Chain has all the versatility of regular MultiSpan Chain but more cost effective.
Specifications Durable
SuperTight Chain is very lightweight yet very strong.
Specifications Load Carrying Capacity
50 lb/ft²
Specifications Material Options
Santoprene
Specifications Number Of Links
2
Specifications Pitch Size
0.98 in | 25 mm
Specifications Sanitary
The open design concept improves cleanability.
Specifications Tight Turning Radius
SuperTight Chain has a tighter horizontal bend radius than MultiSpan.25 mm SupertTight Centerline Radius Formula.
