SPECTEC M18 RF Pickup Sensor with Temperature Probe

SPECTEC M18 RF Pickup Sensor with Temperature Probe

RAD-3deaf7

Discover precision and reliability with the SPECTEC M18 RF Pickup Sensor with optional temperature probe for versatile monitoring capabilities.

$299.99
$299.99
Sale

Initiate Order

SPECTEC M18 RF Pickup Sensor with Temperature Probe

SPECTEC M18 RF Pickup Sensor with Temperature Probe

$299.99

Quantity: 1

Claim Your Seller Account

SPECTEC M18 RF Pickup Sensor with Temperature Probe

SPECTEC M18 RF Pickup Sensor with Temperature Probe

$299.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The SPECTEC M18 RF Pickup Sensor, designed for precision and durability, operates within an extensive frequency range of 0.5 to 6000 Hz. With both air gap open and close face options, it offers versatility for various environments. This sensor is compatible with a range of signal conditioners, providing reliable performance for ferrous object detection. The optional temperature probe enhances monitoring capabilities, extending its functionality for temperature-sensitive applications.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Additional Information Additional Information
Intrinsically Safe and Explosion/Flame Proof versions are also available for Hazardous Locations. In some applications this sensor type can be replaced by an Amplified Variable Reluctance Speed Sensor or Hall Effect Zero Speed Sensor.An optional internal temperature probe is positioned near the face of the sensor.
Options Options
Custom configurations/enclosures, thread sizes, special materials, or temperature probes. Please contact sales.
Signal Conditioners Signal Conditioners
For matching signal conditioners, please refer to SPECTEC’s 4010, 4013 & 4014 series.
Specifications Air Gap Close Face
≤0.130 in
Specifications Air Gap Open Face
≤ 0.160 in
Specifications Connectors
300 Series stainless steel housing Solid Epoxy or Ceramic (8HT) encapsulation TFE or Mica (8HT) insulated wires or cable
Specifications Direct Current Dc Coil Resistanceinductance Rf10
12 Ω | 1.00 mH
Specifications Direct Current Dc Coil Resistanceinductance Rf4
4 Ω | 0.36 mH
Specifications European Conformity Ce Compliance
European Standards (EN)50082-2 | European Standards (EN)55011
Specifications Note For Air Gap Close Face
Sealed Stainless Steel Membrane, for Harsh Environments
Specifications Note For Air Gap Open Face
Sealed Epoxy Surface, High Sensitivity
Specifications Note For Operating Frequency And Air Gap
Depending on Target Mass and Type of Signal Conditioner (8HT: 20% Loss)
Specifications Operating Frequency
≥ 0.5 to ≤6000 Hz
Specifications Oscillation Voltage
3-9 Vpp When Connected to a 4013/4014 | HS Type Signal Conditioner
Specifications Temperature Range 3t
-150 to 330 ºF | -100 to 165 ºC
Specifications Temperature Range 3t With Ntc
-112 to 300 ºF | -80 to 150 ºC
Specifications Temperature Range 4ht
-250 to 400 ºF | -157 to 204 ºC
Specifications Temperature Range 5ht
-450 to 450 ºF | -270 to 232 ºC
Specifications Temperature Range 8ht
-450 to 750 ºF | -270 to 400 ºC
Technical Specs Brands
Spectec
