Spectec PA-50 Pulse Multiplier
Spectec PA-50 Pulse Multiplier
SKU:DIG-5b22fd
Enhance counting accuracy with the Spectec PA-50 Pulse Multiplier for decimal values. Ideal for various input sources. Note: Check Revision E Firmware availability.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Spectec PA-50 Pulse Multiplier
$299.99
Quantity: 1
Claim Your Seller Account
Spectec PA-50 Pulse Multiplier
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Spectec PA-50 Pulse Multiplier is a versatile digital scaler designed to accurately multiply decimal values up to three decimal places. With easy selection through the backlit LCD screen, this device is suitable for a range of inputs including magnetic VRS, RF, digital amplified pickups, and proximity sensors. The Multiplier Range of 0.001 to 100, along with a Maximum Frequency Output of 80 kHz, ensures precise multiplication capabilities. Note: Refer to Revision E Firmware for timing or synchronization applications.
Product Specifications
Note Note
Not suitable for timing or synchronization applications with current Revision D Firmware. This is due to repeatability limitations with pulse width fluctuations from regular VRS/Mag, Hall Effect, and Digital sensors. Revision E Firmware is in development. Please contact factory.
Technical Specs Brands
Spectec
Technical Specs Digital Frequency Input Range
0.3 Hz to 80 KHz
Technical Specs Digital Input Peak To Peak Typesensitivity
0-30V | complementary Metal-Oxide Semiconductor (CMOS) | Positive-Negative-Positive (PNP) | Time to live (TTL)
Technical Specs Digital Output
0-10V | 0-12V | 0-Vs | 0-Vs OCPNP: 0-VsZero Crossing: +8.5V to -8.5V | NPN: 0-5V (TTL)
Technical Specs Direct Current Dc Supply Voltage Vs
12 to 30 V
Technical Specs Magnesium Variable Reluctance Speed Vrs Frequenc
3 Hz to 35 KHz
Technical Specs Magnesium Variable Reluctance Speed Vrs Input Pe
5 mV | 12 mV | 30 mV | 50 mV | 100 mV
Technical Specs Maximum Frequency Output
80 kHz
Technical Specs Multiplier Range
0.001 to 100
Technical Specs Note For Magnesium Variable Reluctance Speed Vrs
Depending on Signal Strength
Technical Specs Note For Multiplier Range
0.001 IncrementsOnly up to 80 kHz Maximum Frequency
Technical Specs Operating Temperature Range With 12 Volt V Suppl
-20 to 75 ºC | -4 to 167 ºF
Technical Specs Operating Temperature Range With 30 Volt V Suppl
-20 to 55 ºC | -4 to 131 ºF
Technical Specs Radio Frequency Rf Frequency Input Range
0.5 Hz to 7 KHz
Technical Specs Radio Frequency Rf Input Peak To Peak Typesensit
4 Ω | 10 Ω
Technical Specs Supply Current Is
75 to 120 mA
