Split Pack Power Transformers
Split Pack Power Transformers
SKU:POW-3555fe
Versatile PC Mount Split Pack™ Power Transformers designed for efficient PC board applications with dual secondary configuration and low capacitive coupling.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Split Pack Power Transformers
$29.99
Quantity: 1
Claim Your Seller Account
Split Pack Power Transformers
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PC Mount Split Pack™ Power Transformers offer a versatile solution for PC board applications with their unique split bobbin design. Unlike standard transformers, these transformers feature nonconcentric windings, eliminating the need for costly electrostatic shielding. Available in a dual secondary configuration with single or dual primaries, these transformers boast a center tap contact type and high efficiency. With primary voltage options of 115V/230V and a compact design, they are ideal for various institutional and government procurement applications.
Product Specifications
Specifications Dimension A
0.250 in
Specifications Dimension B
0.250 in
Specifications Dimension C
1.20 in
Specifications Electrical Rating
1.1 V·A
Specifications Height H
15/16 in
Specifications Length L
1 3/8 in
Specifications Number Of Pins
6
Specifications Primary Frequency
50 Hz | 60 Hz
Specifications Primary Voltage
115 V | 230 V
Specifications Secondary Voltage In Parallel
5.0 V at 0.22 A
Specifications Secondary Voltage In Series
10.0 V CT at 0.11 A
Specifications Transformer Contact Type
Center Tap
Specifications Type
Single Primary
Specifications Weight
0.20 lb
Specifications Width W
1 1/8 in
Technical Notes 0
Hi-pot tested at 2,500 VRMS.PC terminal pin spacing for accurate placement.115 V connect primary in parallel.230 V connect primary in series.Series Connections:Primary - Input 1 & 4Connect 2 & 3Secondary - Input 5 & 8Connect 6 & 7Parallel Connections:Primary - Input 1 & 2Connect 1 & 3. 2 & 4Secondary - Input 5 & 8Connect 5 & 7, 6 & 8For single primary, omit pins 2 and 3.1.1 & 2.5 VA are not offered with mounting holes.
