Square Cylinder Large Compression Latch - 11.4-27.2mm H Grip Range
Square Cylinder Large Compression Latch - 11.4-27.2mm H Grip Range
SKU:IND-6946d1
Secure doors and flaps with our robust Square Cylinder Large Compression Latch. H grip range of 11.4-27.2mm, reserved cam design, durable construction, and IP65 & NEMA 4 compliant.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Square Cylinder Large Compression Latch - 11.4-27.2mm H Grip Range
$24.99
Quantity: 1
Claim Your Seller Account
Square Cylinder Large Compression Latch - 11.4-27.2mm H Grip Range
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Square Cylinder Large Compression Latch in the B series is engineered for reliable, secure door and flap latching. With an H grip range of 11.4mm to 27.2mm and a reserved cam design, this latch ensures a tight seal. Crafted from mild steel and die-cast zinc, the latch features a durable zinc-plated cam and a black powder-coated housing for longevity. Its special left and right features offer versatile installation options. Compliant with Ingress Protection (IP65) and National Electrical Manufacturers Association (NEMA 4) standards, this latch is ideal for industrial applications requiring high performance and durability.
Product Specifications
Specifications Cam Style
Reserved
Specifications Cylinder Size
7 mm
Specifications Cylinder Type
Square
Specifications H Grip Range
11.4 to 27.2 mm
Specifications Industry Standards
Ingress Protection (IP65) | National Electrical Manufacturers Association (NEMA 4)
Specifications Material
Cam: Mild Steel | Housing and Cylinder: Die-Cast Zinc
Specifications Special Features
Left | Right
Specifications Surface Finish
Cam: Zinc Plated | Housing and Cylinder: Black Powder Coated
