SSP Corp. C-276 3-Way Encapsulated Ball Valve - 1/4 in Female BSPT
SSP Corp. C-276 3-Way Encapsulated Ball Valve - 1/4 in Female BSPT
SKU:SSP-fa191f
Enhance fluid control with SSP Corp. C-276 3-Way Encapsulated Ball Valve. Alloy C-276, 0.75 Cv, XQS Flow Pattern, 1/4 in Female BSPT.
Regular price
$85.99
Regular price
Sale price
$85.99
Unit price
per
Initiate Order
SSP Corp. C-276 3-Way Encapsulated Ball Valve - 1/4 in Female BSPT
$85.99
Quantity: 1
Claim Your Seller Account
SSP Corp. C-276 3-Way Encapsulated Ball Valve - 1/4 in Female BSPT
$85.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your fluid control system with the SSP Corp. EB Series C-276 3-Way Encapsulated Ball Valve. Constructed from high-quality Alloy C-276, this valve features a Cv of 0.75 and a Flow Pattern XQS, ensuring precise flow control. The packing is made of Modified PTFE for enhanced durability. With connections of 1/4 in Female BSPT, this valve is designed to meet the highest industry standards for reliability and performance. Trust SSP Corp. for top-notch valves that deliver exceptional results in demanding environments.
Product Specifications
Dimensions A
2.06 in | 52.3 mm
Dimensions B
1.03 in | 26.2 mm
Dimensions C
1.03 in | 26.2 mm
Dimensions D
0.44 in | 11.2 mm
Dimensions E
0 in
Dimensions F
1.53 in | 38.9 mm
Dimensions G
0.188 in | 4.8 mm
Dimensions H
0.78 in | 19.8 mm
Dimensions J
1.53 in
Dimensions Panel Bore
25/32 in
Dimensions W
0.78 in
Specifications Actuation Type
.
Specifications Body Material
Alloy C-276
Specifications Brand Series
EB Series
Specifications Category
Encapsulated
Specifications Connection 1 Size
1/4 in
Specifications Connection 1 Type
Female BSPT
Specifications Connection 2 Size
1/4 in
Specifications Connection 2 Type
Female BSPT
Specifications Connection 3 Size
1/4 in
Specifications Connection 3 Type
Female BSPT
Specifications Cv
0.75
Specifications Flow Pattern
XQS
Specifications Handle Color
Black
Specifications Handle Type
Nylon - Stainless Steel Insert
Specifications Hardware
.
Specifications Orifice
0.187 in | 4.7498 mm
Specifications Packing Material
Modified PTFE
Specifications Production Category
4
Specifications Ssp Pn
43GX4FRT-HC
Specifications Temperature
-65 to 300 ºF | -53 to 148 ºC
Specifications Type
Ball
