Stackable Cap Shaft Collars - Stainless Steel (Two-Piece Split Clamp Type)
Stackable Cap Shaft Collars - Stainless Steel (Two-Piece Split Clamp Type)
SKU:FLA-b38412
Versatile stackable cap shaft collars for secure mounting. Precision-engineered stainless steel design with adjustable, two-piece split clamp type construction.
Regular price
$49.80
Regular price
Sale price
$49.80
Unit price
per
Initiate Order
Stackable Cap Shaft Collars - Stainless Steel (Two-Piece Split Clamp Type)
$49.80
Quantity: 1
Claim Your Seller Account
Stackable Cap Shaft Collars - Stainless Steel (Two-Piece Split Clamp Type)
$49.80
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Stackable Cap Shaft Collars are precision-engineered for versatility and durability, designed to securely mount shafts on components with unmatched ease. Made of high-quality stainless steel and featuring a two-piece split clamp type construction, these collars are stackable, adjustable, and easy to disassemble. With a low profile design, these collars offer high clamping power without marring the surface. The single flat on the Stackable (Cap) version provides a finished, rounded outside surface, perfect for applications where further stacking is not required. Supplied with mounting screws, these shaft collars are ideal for various mounting applications on standard round shafts, thin wall tubes, or split hubs.
Product Specifications
Dimensional Attributes Bore Size
1-1/8 in
Dimensional Attributes Bottom Threaded Hole
1/4-20
Dimensional Attributes Distance Across Flats
1.781 in
Dimensional Attributes Mounting Screw
#10 Flat Head Cap Screw
Dimensional Attributes Outside Diameter
1.875 in
Dimensional Attributes Recessed Screw
No
Dimensional Attributes Screw Material
18-8 Stainless Steel
Dimensional Attributes Screw Size
1/4-28 x 5/8
Dimensional Attributes Width
0.500 in
Specifications Alloy
303
Specifications Approximate Weight
0.21 lb
Specifications Country Of Origin
USA
Specifications Finish
None
Specifications List Price
49.8 USD
Specifications Material
Stainless Steel
Specifications Part Number
19S102CP
Specifications Reach Compliant
Yes
Specifications Rohs2 Compliant
Yes
Specifications Series
Solution
Specifications Type
Low Profile
Specifications Upc Code
662786026379
