Stainless Steel 1-1/4" Connector Check Valve
Stainless Steel 1-1/4" Connector Check Valve
SKU:CNA-4588e6
Durable Stainless Steel 1-1/4" Connector Check Valve with NPT Threads, 1.50 psi Standard Cracking Pressure. Meets CE and ISO 9001 Certifications.
Regular price
$79.99
Regular price
Sale price
$79.99
Unit price
per
Initiate Order
Stainless Steel 1-1/4" Connector Check Valve
$79.99
Quantity: 1
Claim Your Seller Account
Stainless Steel 1-1/4" Connector Check Valve
$79.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Stainless Steel 1-1/4" Connector Check Valve is a high-quality, versatile valve suitable for various industrial applications. This check valve features a National Pipe Thread (NPT) connection, ensuring easy installation in piping systems. With a standard cracking pressure of 1.50 psi, it offers reliable performance under different pressure conditions. Constructed from 316 Stainless Steel for durability, it is available in multiple body materials to suit specific requirements. This valve is designed to meet European Conformity (CE) and ISO 9001 certifications, making it a reliable choice for institutional buyers seeking quality and compliance.
Product Specifications
Note
Made in USA.
Specifications Body Material
316 Stainless Steel = SS | Alloy 20 = A2 | Alloy B = HB | Alloy C-276 = HC | Brass = BR | Carbon Steel = CS | Monel® 400 or Alloy R405 = MO | Titanium = TI
Specifications Body Material Availability
316 Stainless Steel (SS) - Standard | Alloy 20 (A2) - Semi-Standard | Alloy B (HB) - Contact the factory for these or other materials | Alloy C-276 (HC) - Semi-Standard | Brass (BR) - Standard | Carbon Steel (CS) - Standard | Monel® 400 or Alloy R405 - Semi-Standard | Titanium (TI) - Contact the factory for these or other materials
Specifications Certifications
European Conformity (CE) PED 2014/68/EU Complaint | International Organization for Standardization (ISO 9001) Certified
Specifications Nominal Pipe Size
1-1/4 in
Specifications Non Shock Pressure Rating At 100 Degree Fahrenhei
3000 psig
Specifications Note For Material
Listed above are the most common material selections. Please contact the factory for additional options.
Specifications Seat Material
"Metal-to-Metal" = MT | Aflas® = AS | Buna-N = BN | Ethylene Propylene Diene Monomer (EPDM) = EP (EP seats not recommended for use with Carbon Steel valves.) | Fluoro-Elastomer (FKM) = VT | Neoprene = NE | Perfluoroelastomer = KZ | Polytetrafluoroethylene (PTFE) = TF
Specifications Size Code
I
Specifications Special Options
T = FEP Encapsulated Spring (Contact the factory for more options)
Specifications Spring Material
17-7PH Stainless Steel = PH | 316 Stainless Steel = SS | Alloy B = HB | Alloy C-276 = HC | Inconel® X750 or Alloy X750 = IX | Monel® 400 = MO | Titanium = TI
Specifications Standard Cracking Pressure
1.50 psi
Specifications Valve Style
National Pipe Thread (NPT) Threads = CN
